blends¶

Blending operations to use when combining two sets of image data.

Many of these are taken from:

http://www.deepskycolors.com/archive/2010/04/21/ formulas-for-Photoshop-blending-modes.html

http://www.simplefilter.de/en/basics/mixmods.html

Basic Usage: Blends¶

The blending operation functions (blends) are used to blend two sets of image data together. Using a blending operation (a “blend”) works like any other function.

Usage:

>>> import numpy as np
>>> a = np.array([[[0., .25, .5, .75, 1.], [0., .25, .5, .75, 1.]]])
>>> b = np.array([[[1., 75, .5, .25, 0.], [1., 75, .5, .25, 0.]]])
>>> darker(a, b)
array([[[0.  , 0.25, 0.5 , 0.25, 0.  ],
        [0.  , 0.25, 0.5 , 0.25, 0.  ]]])

While the functions themselves are fairly simple, they are given some extra functionality by decorators. Ultimately the true Blending Operation protocol is:

param a:

The image data from the existing image.

param b:

The image data from the blending image.

param colorize:

(Optional). Whether to ensure the two images have the same number of color channels.

param fade:

(Optional.) (From @can_fade.) How much the blend should impact the final output. This is a percentage, so the range of valid values are 0 <= x <= 1.

param mask:

(Optional.) (From @mcan_mask.) An array of data used to mask the blending operation. This is also a percentage, so a value of one in the mask means that pixel is fully affected by the operation. A value of zero means the pixel is not affected by the operation.

return:

A numpy.ndarray object.

rtype:

numpy.ndarray

Colorize, Array Shape, and Color Channels¶

The blends themselves don’t care about the dimensionality of the given arrays. It just needs the two arrays to have the same shape by the time it does the blend. While this was originally written for image data, to the algorithms themselves, it’s all just floating-point math.

However, there is one case where a bias towards image data shows up:

You pass two arrays with differing shapes,

The size of their last dimension is different,

One of the two arrays has a last dimension with size three.

To perform the blending algorithm, the two arrays must be the same shape. In most cases, differences between the two shapes will be handled through the pjimg.blends.will_match_size() decorator, which adds zeros to the smaller array to make their sizes match. However, in the case described above, something different happens.

Since color image data often has a last dimension size of three, representing color channels, the case above is intercepted by the img.blender.common.will_colorize() decorator. That decorator assumes the array that doesn’t have a last dimension size of three is single channel image data (“grayscale”) and will add a new last dimension of size three. The values will be the original single value repeated three times. To demonstrate:

>>> from pjimg.blends import will_colorize
>>> a = np.array([
...     [1.0, 0.5, 0.0, ],
...     [0.5, 0.0, 0.5, ],
...     [0.0, 0.5, 1.0, ],
... ])
>>> b = np.array([
...     [[0, 0, 0], [0, 0, 0], [0, 0, 0], ],
...     [[0, 0, 0], [0, 0, 0], [0, 0, 0], ],
...     [[0, 0, 0], [0, 0, 0], [0, 0, 0], ],
... ])
>>>
>>> @will_colorize
... def spam(a, b):
...     return a
...
>>> a_ = spam(a, b)
>>> a_
array([[[1. , 1. , 1. ],
        [0.5, 0.5, 0.5],
        [0. , 0. , 0. ]],

       [[0.5, 0.5, 0.5],
        [0. , 0. , 0. ],
        [0.5, 0.5, 0.5]],

       [[0. , 0. , 0. ],
        [0.5, 0.5, 0.5],
        [1. , 1. , 1. ]]])
>>> a.shape
(3, 3)
>>> a_.shape
(3, 3, 3)

The value returned by `spam()` in the demonstration has an extra dimension of size three added, and the values are three copies of the values in the original `a``.

This can be turned off by passing `False` to the `colorize` parameter of the blend.

Registration¶

All blending operations are registered in dict pjimg.eases.blends for convenience, but they can also be called directly.

Blend Operations¶

The examples in the following blends will show the result when a simple horizontal gradient:

>>> from pjimg.sources import Gradient
>>> a = Gradient('h').fill((1, 720, 1280))

The simple horizontal gradient `a`. — The simple horizontal gradient a.¶

is blended with a simple vertical gradient:

>>> b = Gradient('v').fill((1, 720, 1280))

The simple horizontal gradient `b`. — The simple horizontal gradient b.¶

Replacement Blends¶

pjimg.blends.replace(a: ndarray[tuple[int, ...], dtype[float64]], b: ndarray[tuple[int, ...], dtype[float64]]) → ndarray[tuple[int, ...], dtype[float64]][source]¶

Simple replacement filter. Can double as an opacity filter if passed can_fade amount, but otherwise this will just replace the values in a with the values in b.

Parameters:

a – The existing values. This is like the bottom layer in a photo editing tool.
b – The values to blend. This is like the top layer in a photo editing tool.
colorize – (Optional). Whether to ensure the two images have the same number of color channels.
fade – (Optional.) The amount the blended values should affect the existing values. This is a float between zero and one, where zero is no effect and one is full effect. See blendser.common.can_fade() for more details.
mask – (Optional.) An image mask that is used to determine the effect the blend should have on the existing values. This is a numpy.ndarray of floats between zero and one, where zero is no effect and one is full effect. See blendser.common.can_mask() for details.

Returns:

An numpy.ndarray that contains the values of the blended arrays.

Return type:
